Rapidor Freeze is a unique dual-curtain high speed freezer door system for high-use freezer doorways, with two PVC fabric curtains in one frame with a central 250mm airlock providing a effective insulated zone between positive & negative temperature areas. An efficient warm air blower maintains the temperature of the zone to prevent icing up whilst minimising running costs. The high speed door also includes a heating kit for the side guides and motor, allowing the door to be used successfully at temperatures as low as -35°C. The combination of those features provides significant energy savings over traditional freezer doors and chiller doors.
These high speed industrial freezer doors also have a self-repairing design with a soft-bottom edge, meaning that if the door curtain is hit by traffic then it will automatically reinsert itself back into the tracks when next operated. This helps to greatly reduce the cost of maintenance and repair with no downtime or emergency callout costs. The freezer doors fast operation of up to 1800mm/second also ensures that productivity is enhanced and the reduced cycle time helps to reduce energy bills.
For high usage doorways or where there is a large difference between temperature or humidity either side of the doorway, we recommend upgrading to our revolutionary Rapidor Freeze Air high speed freezer door which adds an integral air curtain system for effective separation between environments when the door is open as well as closed.
Key features/benefits
The innovative design of the Rapidor Freeze rapid rolling freezer doors means if is the best value solution when a reliable, high speed freezer door is required for cold storage, freezer and chiller/cooler door applications.
- High speed ensures efficiency and low cycle time for reduced running costs
- Multi-function control panel enables many operation & automation options
- Self-repairing feature minimises downtime & repair costs
- Wide range of colour options available
- Excellent insulation performance for effective separation of positive and negative temperatures
- Tested to 1,000,000 cycles for guaranteed durability
- Reduces energy costs for cold storage areas through innovative design
- Allows safe traffic flow between freezer and ambient areas with high temperature difference
I would thoroughly recommend Tekta to anyone in the temperature-controlled storage industry
Option Packs
Several options are available to further tailor the performance of the door to bespoke requirements.
Stainless steel
Upgrade to stainless steel construction
Activation Methods
A wide variety activation methods are available for the doors which allows them to be configured to the requirements of each site, including remote control, pull cord, induction loop and motion sensor.
Emergency Opening
Counterweight or UPS battery back-up system to allow the door to open for escape in a power failure
View our full range of Chiller, Freezer & Cold Room Doors here
Like to know the What, Where, When & Why of Speed Doors?
